Product Number: GMTTA04
Outdoor Tactical tight buffered (core bonded design) PUR jacket 4f SM OS2 G.652.D & G.657.A1.
Outdoor Tactical tight buffered optical fiber cable with core bonded design with Polyurethane (PUR) outer jacket. 4 fibers SM OS2 G.652.D & G.657.A1.
-
Availability:
Global
-
Global inventory:
Available
Specifications
Product Overview
|
Environmental Space |
Indoor/Outdoor |
|---|---|
|
Suitable Applications |
For outdoor and indoor use. These metal-free mobile cables have been designed for de-spooling and re-spooling repeatedly. Support all computer network applications such as FDDI, Gigabit Ethernet and ATM Easy to install. Not Recommended for direct burial. Core-bonded Polyurethane jacket providing simple installation. |
Construction
Fiber Cable Construction
| Fiber Type | Fiber Grade acc. ITU-T | Fiber Count |
|---|---|---|
| OS2 | G.652D & G.657A1 | 4 |
|
Fiber Color Coding |
TIA coding (Gxxxxxx.T): Blue, Orange, Green, Brown |
|---|
Buffer Specification
| Fiber Type | Buffer Construction | Buffer Material | Buffer Diameter |
|---|---|---|---|
| OS2 | Tight | Nylon | 0.9 mm |
|
Cable Core Water Tight |
Yes |
|---|---|
|
Cable Core Waterblocking |
Waterblocking Aramid Yarns |
|
Bulk Cable Weight |
31 kg/km |
Physical Specifications
|
Type of Armor |
Non-Armored |
|---|
Jacket Specifications
|
Number of Jackets |
Single Jacket |
|---|
Outer Jacket Specifications
Outer Jacket
| Material | Color | Nominal Diameter | Ripcord |
|---|---|---|---|
| PUR - Polyurethane | Black | 5.8 mm | Yes |
Optical Characteristics
|
Max. Attenuation at 1310 nm |
0.40 dB/km |
|---|---|
|
Max. Attenuation at 1550 nm |
0.30 dB/km |
|
Max. Attenuation at 1625 nm |
0.30 dB/km |
Mechanical Characteristics
Mechanical Tests
| Description | Tested Standard | Requirement/Value | According to Family Specification |
|---|---|---|---|
| Cable Min. Bend Radius Installation (Short Term) | IEC 60794-1-21-E6 | 46.4 mm | |
| Cable Min. Bend Radius Operation (Long Term) | IEC 60794-1-21-E11 | 23.2 mm | |
| Cable Max. Tensile Strength Installation (Short Term) | IEC 60794-1-21-E1 | 1650 N (371 lbf) | |
| Cable Max. Tensile Strength Operation (Long Term) | 550 N (124 lbf) | ||
| Cable Max. Crush Resistance Installation (Short Term) | IEC 60794-1-21-E3 | 5 kN/m | IEC 60794-2-20 |
| Cable Max. Crush Resistance Operation (Long Term) | IEC 60794-1-21-E3 | 3 kN/m | IEC 60794-2-20 |
Temperature Range
|
Operating Temperature Range |
-70 °C to +85 °C |
|---|---|
|
Installation Temperature Range |
-5 °C to +50 °C |
|
Storage Temperature Range |
-70 °C to +85 °C |
Product Material
|
UL Rating/Flame Test |
Non-UL Rated |
|---|
Standards
|
IEC Flammability |
IEC 60332-1-2 |
|---|---|
|
REACH |
Compliant |
|
ISO/IEC Compliance |
IEC 60794, ISO/IEC 11801-1 |
|
UV/ Sunlight Protection |
Yes |
History
|
Update and Revision |
Revision Number: 0.162 Revision Date: 09-17-2024 |
|---|
Information
|
Update and Revision |
Revision Number: 0.162 Revision Date: 09-17-2024 |
|---|
Part Numbers
| Item # | Color | Put-Up Type | Length | EAN |
|---|---|---|---|---|
| GMTTA04.012100 | Black, Glossy | Reel | 2,100 m | 8719605076717 |
