PPIRRS

PPRO Rack manager without LCD display

...
PatchPro 19"RACK MNG, Without DISPLAY, 30 PP CONNECTED MAX, BLACK, ROHS

Regions Available: Global
English
Request Quote
Share
Get Product Alerts

Specifications
Report An Error
Product Overview

Suitable Applications

Horizontal and building cabling for Intelligent (RFID based) Patching. Support current and future Category 6a and 6 applications, such as: 10GBase-T (10 Gigabit Ethernet), 1000Base-T (Gigabit Ethernet), 100 Base-T, 10 Base-T, FDDI, ATM

Physical Characteristics (Overall)

Height

35 mm

Width

150 mm

Depth

93 mm

Packaging

Individually packaged in a box.

Weight

0.2 kg
Connectors
Materials
Description Material Color
Body of the Rack Manager ABS Plastic Grey-white
Interface USB, LAN, Bus
Construction and Dimensions

Max Capacity

30 Panels

Electrical Characteristics

Current Rating

1.500 A
Temperature Range

Storage Temperature Range

-20°C To +85°C

Operating Temperature Range

0°C To +40°C

Standards

TIA/EIA Compliance

ISO/IEC 11801-1:2017; TIA 568-C.3

Applicable Environmental and Other Programs

Environmental Space

Indoor

EU Directive 2011/65/EU (RoHS 2)

Yes

MII Order #39 (China RoHS)

EUP 50

Related Part Numbers

Related Parts

PatchPro Connectivity, Upgrade RFID kit

History

Update and Revision

Revision Number: 0.34 Revision Date: 02-27-2024

Show All Specifications
Hide Specifications
Part Numbers
Item # Color Packaging
PPIRRS Black Individually packaged in a box.
