50105HF

Belden High flex CAT5e industrial ethernet cable

...
Belden High flex CAT5e industrial ethernet 4P 26AWG cable, oil resistant, 80C, 30V, VW-1 ROHS

Regions Available: Global
English
Request Quote
Share
Get Product Alerts

Specifications
Report An Error
Product Overview

Suitable Applications

Internal wiring of electronic equipment and appliances.

Construction Details
Conductor
Element Size Material
Pair(s) 26 AWG BC - Bare Copper
Insulation
Material Nom. Insulation Diameter Color Code
PE - Polyethylene 1.0 mm (0.039 in) White/Blue, Blue, White/Orange, Orange, White/Green, Green, White/Brown, Brown

Table Notes

All Four Pairs laid up together on a filler wrapped by PET & Wrap tape binder

Outer Shield
Shield Type Material Coverage Notes
Braid Tinned Copper (TC) 85% Drain wire 25AWG(7x33) TC is used along with TC wire braid
Outer Jacket
Material
PVC - Polyvinyl Chloride

Overall Cable Diameter (Nominal)

6.7 ± 0.3 mm

Electrical Characteristics
Electricals
Max. Conductor DCR
149 Ω/km @ 20°C
High Frequency
Frequency Max. Insertion Loss (Attenuation) Min. NEXT [dB] Min. RL (Return Loss) [dB] Nom. Characteristic Impedance [Ohm]
1 3.4 dB/100m 65.3 20 100
4 MHz 6.8 dB/100m 56.3 23 100
8 MHz 9.6 dB/100m 51.8 24.5 100
10 MHz 10.8 dB/100m 50.3 25 100
16 MHz 13.7 dB/100m 47.2 25 100
20 MHz 15.4 dB/100m 45.8 25 100
25 MHz 17.4 dB/100m 44.3 24.3 100
31.25 MHz 19.5 dB/100m 42.9 23.6 100
62.5 MHz 28.3 dB/100m 38.4 21.5 100
100 MHz 36.6 dB/100m 35.3 20.1 100
Voltage
UL Voltage Rating Breakdown Voltage
30 V 500V ac/5min
Mechanical Characteristics
Temperature
Operating
-20 ℃ to + 80℃

Table Notes

Flexibility, Trailing Chain: ≥ 1 Million Cycles, Chain Distance: 350 mm, Bending radius: 50mm, Acceleration: 10m/s2, Speed: 70 Cycles/min.

Standards and Compliance

Flammability / Reaction to Fire

VW-1

AWM Compliance

AWM 20276

Data Category

Category 5e

European Directive Compliance

EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2)

APAC Compliance

China RoHS II (GB/T 26572-2011)

Product Notes

Notes

Max. Transmission Length : 60 M

History

Update and Revision

Revision Number: 0.18 Revision Date: 08-13-2024
